Olbrich Tief-/Siebdruckstation 5 – Varnishing & Coating Equipment

Available

  • Production Year
  • No Colors

Reference number: A4P02287

Is applying a seven-color coating to the base with final packaging in consumer rollsCan produce the following groups of wallpaper: foamed vinyl, paintable wallpaperWidth: 0.53 – 1.06 mMaximum mechanical speed: 150 m/minuteProduction speed: 60-110 m/minuteEffective power consumption of electricity: 300 kW/hTemperature of heat transfer agent (oil): 3000 ℃Pressure of compressed air: 6 barRolls produced: 16 millionYear of equipment conservation: 2018MAIN COMPONENTS OF THE PRINTING LINE:Automatic bobbin unwinding and gluing unitUnit for preliminary drying, tensioning and cooling of the baseTable for longitudinal leveling of basePrinting stations – 7 racks/columns:– 1-st rack/column – intaglio/gravure printing or screen printing (to choose from), with double drying chamber and cooling system– 2-nd – 6-th racks/columns – only for screen printing, with one drying chamber and cooling system– 7-th rack/column – only for screen printing, without oven and cooling;Video monitoring system of the baseGlitter scattering unitLongitudinal drying channel (six sections)Cooling unitPrinted cloth flatten areaCutting, trimming and edge removal systemPulling accumulation of wallpapersWinding and cutting into rolls machinePacking machineMain control panelElectrical switchboards (electronic equipment by Siemens

Please note that this description may have been translated automatically. Contact us for further information. The details are only indicative.
